ROTOR Chainrings

Rotor 52 NOQ chainring for Shimano & Rotor 12s cranksets

ROTOR CHAINRINGS: Compatibility, Shapes, and Variety

In our "Rotor Chainrings" category, discover a complete range of chainrings designed to fit various transmission systems and bike configurations. We offer models compatible with Shimano, SRAM, Campagnolo, as well as options for road, gravel, cyclocross, and track. Each chainring is precision-engineered to provide optimized performance, allowing cyclists to configure their transmission to meet specific needs.

Shimano 12-11s Chainrings: Best Sellers

Our Shimano 12-11s chainrings are fully compatible with all Shimano 4-arm cranksets and Rotor 4-arm spiders. Available in two versions—cut-out and aero—they meet the needs for performance and aerodynamics:

  • Cut-out versions: From 50 to 54 teeth, perfect for cyclists seeking lightness and rigidity.
  • Aero versions: From 54 to 58 teeth, ideal for time trial and triathlon competitions.

Types of Available Chainrings:

Compatibility with Groups and Cranksets:

  • Shimano 12-11s: These chainrings are fully compatible with Rotor 4-arm cranksets and Shimano 12 and 11-speed cranksets, ensuring maximum flexibility and versatility for cyclists using these configurations.
  • SRAM AXS and 107mm: The offering includes two types of chainrings: 107mm, compatible with SRAM spiders, and Rotor 110mm chainrings, specifically designed for AXS groups, to be mounted on Rotor 4-arm cranksets.
  • Campagnolo: Our Campagnolo offering focuses on older models. We generally recommend staying with original Campagnolo cranksets for optimal compatibility.
  • 5-arm (110mm and 130mm): Standards associated with 10 and 11-speed transmissions. The 110mm is ideal for smaller chainring sizes (34 and 36 teeth), while the 130mm is suitable for larger configurations starting from 39 teeth.
  • Track (144mm): These chainrings are available from 46 to 56 teeth and mount exclusively on track cranksets with a 144mm BCD. Aero in shape, these chainrings are perfect for Rotor track spiders.
Rotor Chainrings - Wide Selection for Shimano & Sram Drivetrains | Velo-Perso.com

Subcategories

  • Shimano 12-11S...

    Shimano Ultegra R-8100 crankset with Rotor 53/39 chainrings

    Discover our selection of Rotor chainrings compatible with Shimano 12-speed drivetrains, specifically designed to enhance the performance of your Shimano 12 and 11-speed systems.

    Compatibility with drivetrains and cranksets:

    • Compatible drivetrains: Shimano 12-speed and 11-speed.
    • Compatible cranksets: Shimano 105 Di2 (FC-R7100), Ultegra 12-speed (FC-R8100), and Dura-Ace 12-speed (FC-R9200).
    • Shimano power meters: Open-design chainrings are fully compatible with FC-R8100-P and FC-R9200-P models. However, aero chainrings are not compatible with Shimano power meters. As an alternative, we recommend Rotor power meters for superior performance.

    Compatibility with Rotor Direct Mount:

    All our chainrings are also compatible with Rotor Direct Mount 4-arm systems, including:

    • Rotor DM 4-arm spider.
    • Inspider power meter spider.
    • Aero MAS spider.

    Shimano and Rotor single chainrings:

    Easily convert your Shimano 12 or 11-speed groupset into a single chainring configuration with our dedicated selection, perfect for disciplines like cyclocross, gravel, or triathlon.

    Advantages of Rotor kits for Shimano cranksets:

    Opt for a complete kit that includes:

    • Small chainring + large chainring.
    • Chainring bolts compatible with your Shimano 12-speed crankset. These kits offer an excellent price-to-performance ratio and ensure quick and secure installation.

    Details on chainring bolts and covers:

    • Two models of chainring bolts are available: Ultegra 8100 and Dura-Ace 9200.
    • For Shimano 105 Di2 cranksets (FC-R7100), classic chainring bolts are required. While functional, they are slightly less aesthetically pleasing.

    With our competitive pricing and advanced compatibility with Shimano standards, this section of our website is the perfect place to optimize or customize your Shimano 12 and 11-speed groupsets.

  • Sram AXS

    FAQ: Rotor Chainrings Compatible with SRAM

    1. Are these Rotor chainrings compatible with all SRAM drivetrains?

    Yes, the Rotor chainrings presented here are compatible with SRAM AXS 12-speed drivetrains. They are available in two main configurations:

    • BCD 107 mm: for stars specific to SRAM groups.
    • BCD 110 mm: for Rotor stars or compatible systems.

    2. What are the benefits of Rotor chainrings for SRAM AXS drivetrains?

    • Perfect compatibility with 12-speed groups.
    • Available in oval (Q-Rings) and round versions to suit cyclist preferences.
    • Made of CNC-machined aluminum, ensuring an excellent stiffness-to-weight ratio.
    • Customizable tooth sizes for optimal performance based on your riding style.

    3. Are Q-Rings compatible with SRAM AXS derailleurs?

    Yes, Q-Rings (Rotor oval chainrings) are fully compatible with SRAM AXS derailleurs. They work perfectly with SRAM electronic systems and offer smoother pedaling by reducing dead spots.

    4. What chainring sizes are available?

    • For double chainring Rotor cranks (BCD 110): 48/35, 50/37 in round or oval options.
    • For double chainring SRAM cranks (BCD 107): 48/35 and 50/37 in oval only.

    6. Do these chainrings require specific adapters?

    BCD 107: The chainrings mount directly onto SRAM stars.
    BCD 110: These chainrings require a specific Rotor star if your current system does not include a compatible star.

    7. How do I install a Rotor chainring on a SRAM drivetrain?

    For SRAM stars (107 mm):

    1. Remove the old chainring by unscrewing the fixing bolts.
    2. Install the new Rotor chainring, ensuring proper tooth alignment for optimal shifting.
    3. Tighten the bolts to the recommended torque (usually 5-6 Nm).
    4. Test gear shifting and adjust if necessary.

    For Rotor stars (110 mm):

    1. Remove the old chainring by unscrewing the fixing bolts.
    2. Install the new Rotor chainring, ensuring proper alignment: the anti-drop pin must be positioned behind the crank arm.
    3. Tighten the bolts to the recommended torque (7-8 Nm).
    4. Test gear shifting and adjust if necessary.

    8. Are Rotor chainrings durable?

    Yes, Rotor chainrings are designed to last. Made from high-quality 7075 aluminum, they resist wear and maintain their performance even after thousands of kilometers.

    Tips for maximizing their lifespan:

    • Regularly lubricate with high-quality products.
    • Keep the chain and chainrings clean.
    • Replace the chain before it becomes overly worn.

    9. How do I choose between a round chainring and an oval Q-Ring?

    • Round chainring: Ideal for cyclists who prefer a traditional pedaling style.
    • Oval Q-Ring: Recommended to improve pedaling smoothness, reduce dead spots, and enhance efficiency on long rides or climbs.

    10. Can I use these chainrings with a Shimano chain?

    No, Rotor chainrings designed for SRAM AXS are specifically optimized for SRAM 12-speed chains. For Shimano compatibility, specific Rotor chainrings are required.

    11. What tools are needed to install these chainrings?

    • An Allen key (typically 4 or 5 mm) to remove and install the bolts.
    • A torque wrench to ensure proper tightening.

    12. What is the maximum tooth size for Rotor chainrings compatible with SRAM AXS?

    The maximum size offered is 50/37, as most SRAM AXS groups are designed for a maximum of 50 teeth.

    However, with SRAM releasing in 2024 its Red AXS groups for chainrings of 54 teeth or more, keep an eye on new Rotor arrivals on velo-perso.com. You might soon find larger Rotor chainrings for your SRAM AXS drivetrain.

  • Shimano GRX 11S

    Double chainrings for Shimano GRX groupsets. 110/80mm BCD

  • Shimano Rotor 4 hole...

    Rotor 4 hole chainrings with a 110mm BCD are the most popular chainrings. They are available in many variations.

  • 5 arm chainrings

    Rotor 5 arm 110mm BCD chainrings are the reference of the early 2010's. We keep available a little amount of these chainrings. Most of the time they have been replaced by the 4 hole standard

  • Standard 130

    Rotor 5 arm chainrings with 130mm BCD. This standard was popular in the 2000's. Then it was replaced by 5 arm 110 BCD. We have a little inventory of these 130mm chainrings in order to use vintage cranksets with this standard.

  • Campagnolo

    Rotor 113mm and 135mm chainrings to assemble on Campy cranks of the 2000's and early 2010's. Most of sizes are discontinued.

  • NoQ (round)

    This category includes all our Rotor round chainrings. It's another way for you to sort chainrings and find the round chainrings that you need for your crankset.

  • Qrings/Ovalized
  • Spidering...

    Single or double directmount chainrings. Spidering is one piece of aluminum that combines spider and 1 or 2 chainrings. They are supposed to simplify the drivetrain and to add extra choice of setups: micro compact double chainrings, very small single chainrings for MTB/Gravel...

  • Single chainring

    Single chainrings are becoming more and more popular, especially on gravel bikes. Find here all Rotor single chainrings available : 4 arm chainrings for Rotor spiders and Inspider powermeter, Direct Mount spiderings single chainring. The new standard 2023 is called "universal tooth" and will be compatible with all 11 & 12s chains.

  • Track/Fixie

    Find here the perfect chainrings for your track or fixie bike. You'll enjoy the great stiffness of these 144mm BCD chainrings made in Spain by Rotor. Select the size of chainring that you need for your track discipline. They are compatible with the Rotor track spider called track30.
